Brief introduction
Container straddle carrier is the most economical solution for heavy-duty, overloaded transport, transportation and industry. Its maneuverability, small footprint and highly customizable features provide complete independence when moving containers and extreme loads. Container straddle carrier is particularly suitable for industrial distribution such as logistics distribution, freight yard transportation, warehouse storage, workshop site transfer and more, with low flow and low investment.
Sketch
Advantages Of container straddle carrier
1.Finite element and dynamic simulation technology is used to ensure steel structure useful life over 20 years.
2. Painting is in accordance with the port standards. After sandblasting treatment, then primer, middle paint and top coating start in sequence.
3.Solid tires are more endurable with lower maintenance cost.
4.Machine is light with low wheel load pressure, and can work in different working conditions.
5.CAN bus system, signals are transmitted by data with long distance transmission, accurate data and high reliability.
6.High-performance electrical components: SYMC controller, P+F sensor, Amphenol connector.
7.Use mature hydraulic hand lever, reducing breakdown, easy for both operation and maintenance.
Main technical data
|
No. |
Item |
Parameter |
|
1 |
Capacity |
35ton |
|
2 |
Dimensions(LxWxH) |
7100x5200x6100mm |
|
3 |
Inner width |
3200mm |
|
4 |
Min. turning radius |
7500mm |
|
5 |
Lateral movement range |
±200mm |
|
6 |
Dead weight |
~24ton |
|
7 |
Spreader |
20’/40’ |
|
8 |
Diesel engine |
Cummins(USA) |
|
9 |
Travelling motor |
Danfoss (USA/Italy) |
|
10 |
Control mechanism |
SYMC |
|
11 |
Pressure sensor |
GEFRAN(Italy) |
|
12 |
Intermediate relay |
OMRON(Japan) |
|
13 |
Fuse Terminals, Terminal Blocks |
WAGO(Germany) |
|
14 |
Ignition key switch |
COBO(Italy) |
|
15 |
Proximity switch |
P+F(Germany) |
|
16 |
Complete machine connector |
Amphenol(USA) |
