Brief introduction
360° rotating jib crane is a light working duty crane which is used with electric chain hoist or wire rope type electric hoist. It consists of fixed column, swing jib, electric hoist and electrical control system. The column is fixed on the concrete foundation by anchor bolts, and the electric hoist lifting/lowing goods and runs on swing jib by electric control.
360° rotating jib crane has the advantages of economical design, easy operation, small occupation space and large working range. And was widely used in machinery manufacturing, assembly lines and warehouses, docks, laboratories and other materials handling operations. It Is an ideal lifting equipment for improving work efficiency and working conditions for the enterprise.
Sketch
Main technical data
| Rated capacity | t | 0.5 | 1 | 2 | 3 | 5 | 10 |
| Beam length | mm | 2000~6000 | |||||
| Lifting height | mm | 2000~6000 | |||||
| Lifting speed | m/min | 8; 8/0.8 | |||||
| Travelling speed | m/min | 10; 20 | |||||
| Turning speed | r/min | 0.76 | 0.69 | 0.6 | 0.53 | 0.48 | 0.46 |
| Turning degree | degree | 360° | |||||
| Classification group | ISO A3 | ||||||
| Power source | 380V, 50HZ, 3 phase (or custom made) | ||||||
| Working temperature | -20~42°C | ||||||
| Control model | Pendant control or remote control | ||||||
Main parts of 360 rotating jib crane
Packing and delivery of 360 rotating Jib crane
